Myka Surface Wet - Static White

Myka Surface Wet – Static White

Surface Mount Wet Location Linear 24V System

Overview

Specifications

24VDC Class 2 and IP68 rated for wet locations, fixtures made to order up to 144”. Fixtures can be linked up to 48’ depending on output
Suitable for undercabinet, millwork, direct view, grazer, vanity, architectural reveals, accent lighting and surface mount applications
Dot free even illumination with frosted lens and high color outputs
High Color Quality options offer premium quality and vibrant colors with R9 values up to 97
High Efficacy options offer best in class output and efficacy with over 425 lm/ft and up to 76 lm/W
Proprietary strong bond solder method handles up to 50 lbs of pull force on wire leads and connectors
3 Year warranty

CCT: 2700K, 3000K, 3500K, 4000K
CRI: 95+
Output / ft: 144 lm/ft, 148 lm/ft, 200 lm/ft, 241 lm/ft, 267 lm/ft, 293 lm/ft, 428 lm/ft
Mounting: Surface
Type: Linear Fixture
Input Voltage: Low Voltage
Color: Static White
Wattage / ft: 1.9 W/ft, 2.8 W/ft, 3.5 W/ft, 4.8 W/ft, 6.0 W/ft, 6.5 W/ft
Rating: IP68
Lens Aperture: 0.40 inch
Size: 0.49 in
Height: 0.49 in
Lens: Clear, Frosted
Operating Temperature: -15°F to 125°F
Sustainability: Declare, JA8/Title 24, RoHS/Reach
Made In: Made in America
Warranty: 3 Years
Product Number: MKW
