Luminii

Cylinders

Leto 44 Plus Wall Mount Up Down

Square Cylinder

Overview
Specifications
  • Faceted and Smooth metal reflectors provide beam spreads between 10° to 80°.
  • Two output options available up to 1000 lumens up and
    1000 lumens down.
  • Nine driver selections available to cover wide range of applications.
  • Five year warranty.
  • CCT: 2500K, 2700K, 3000K, 3500K, 4000K, 6500K
  • CRI: 90+
  • Output: 1000 lm, 700 lm
  • Function: Fixed
  • Mounting: Wall Mount
  • Shape: Square
  • Color: Static White
  • Optics: 10°, 18°, 30°, 45°, 60°, 80°
  • Wattage: 6.0 W, 9.1 W
  • Dimming Protocol: 0-10 V, Casambi, DALI, DMX, Phase
  • Height: 3.74 inch
  • Sustainability: Declare, JA8/Title 24, RoHS/Reach
  • Made In: Made in Canada
  • Warranty: 5 Years
  • Product Number: LET44P-WM
Specsheets
Install Guides
Cross Reference Guide
IES Files
Leto 44 Plus Wall Mount Up Down Static White Spec Sheet
1.99 MB
PDF
Leto 44 WM Installation Guide
462.11 KB
PDF
Senso Part Number Cross Reference Guide
PDF
LET44P-F1060-35K-1010-NA.ies
208.25 KB
IES
LET44P-F1860-35K-1010-NA.ies
208.25 KB
IES
LET44P-F3060-35K-1010-NA.ies
208.25 KB
IES
LET44P-F4560-35K-1010-NA.ies
208.25 KB
IES
LET44P-F6060-35K-1010-NA.ies
208.25 KB
IES
LET44P-S3060-35K-1010-NA.ies
208.25 KB
IES
LET44P-S4560-35K-1010-NA.ies
208.25 KB
IES
LET44P-S8060-35K-1010-NA.ies
208.25 KB
IES
