Kilo Recessed - Static White

Kilo Recessed – Static White

Recessed Linear 24V System

Overview

Specifications

24VDC Class 2 fixtures made to order up to 144”. Fixtures can be linked up to 24’ depending on output
Available with plenum rated wire leads or with integral junction box for splice connection
Continuous Lens may be ordered separately for multi-fixture runs to create an even, seamless appearance
Mounting hardware is included with the fixture
Average Life (L70): 50,000hrs
Proprietary strong bond solder method handles up to 50 lbs of pull force on wire leads and connectors
Dot free even illumination with frosted lens
High Color Quality options offer premium quality and vibrant colors with R9 values up to 97
High Efficacy options offer best in class output and efficacy with over 1490 lm/ft and up to 105 lm/W
7 year warranty

CCT: 1900K, 2200K, 2400K, 2500K, 2700K, 3000K, 3500K, 4000K, 4100K
CRI: 98
Output / ft: 397 lm/ft, 408 lm/ft, 550 lm/ft, 663 lm/ft, 735 lm/ft, 806 lm/ft, 1179 lm/ft, 1492 lm/ft
Mounting: Recessed
Type: Linear Fixture
Input Voltage: Low Voltage
Color: Static White
Wattage / ft: 3.8 W/ft, 5.6 W/ft, 7.0 W/ft, 9.6 W/ft, 12 W/ft, 13 W/ft, 15 W/ft
Rating: Damp
Lens Aperture: 1.05 inch
Size: 1.50 in
Height: 1.50 in
Lens: Clear, Frosted
Operating Temperature: -5°F to 125°F
Sustainability: Declare, JA8/Title 24, RoHS/Reach
Made In: Made in America
Warranty: 7 years
Product Number: KR
